AVER VC-520 Pro USB Video Conference System.

Aver has assigned Nasco – as their master distributors for Pakistan region & VC 520 pro is one of the worlds leading product in the category of USB based video conferencing systems. The VC 520 pro offers features & functionalities which makes it stands out from the rest of the video conferencing solutions available from other brands. Features & functionalities like

  • Smart framing technology
  • IP & Network management
  • Live streaming over social media
  • Full HD resolution with stereo speaker phone

Details of VC520pro in Pakistan are mentioned below.



For Price Updates Please Contact us

Best video conferencing system in Pakistan ( Most power full Zoom !!)

The AVer vc520pro video conferencing system is regarded as one the best video conferencing systems not only in Pakistan but world wide as well due to itas high end functionalities. The video conferencing camera has the ability to capture even the farthest of participants sitting in the conference room or auditorium.

AVer VC 520 Pro Speaker Phone ( Touch sensitive control system)

VC520pro video conference systems offer amazing sound quality & pick up from its speaker phone having built in microphone arrays. The estimated audio pickup range of speaker phone is around 6m. The speaker phone comprises of  touch sensitive volume control setup along with an option of muting & un muting microphone as well. A small test of audio quality of speaker phone can also be witnessed here.

Aver Vc520 pro Expansion Speaker phone & microphones ( Enhance audio coverage)

The vc 520 pro speakerphone is fully expandable to enhance the audio coverage of the video conferencing system. The master speaker phone can either be connected with 2 – additional speaker phones or a combination of 2 – pairs of microphones.



Aver Vc 520 pro video conferencing solution in Pakistan ( Great panning angles !)

The Vc520 pro video conference systems is specifically designed to capture audience even in large auditoriums. With great panning & tilting angles the video conferencing system allows even audience seated on the extreme left & right to be captured perfectly.

Tilting angles of Vc520Pro video conferencing system in Pakistan.

With high end panning angles, the VC520pro video conferencing system also has been equipped with high end tilting angles as well. The video conferencing camera has the ability to tilt at an angle of +90 degree & -30 degree.

VC520Pro video conference system in Pakistan ( Brightness Control)

The AVer VC 520pro can be fully controlled through the software. The software integration offers multiple capability enhancement to the VC520pro video camera system. The controller can manually select the brightness controls as per the ambient light situation of the room. This feature allows the perfect visual to be broadcasted to the remote end.

Vc520pro video conferencing solution in Pakistan( Wide dynamic range settings)

With manual setting control through the software the VC520pro video conferencing system can also control the wide dynamic range settings. Wide dynamic range maintains constant clarity in highly contrast environments. With manual settings optimum results can be broadcasted to the remote end.

Zoom video conferencing system in Pakistan( Camera flipping technology)

The VC520pro video conferencing camera image can be flipped. This allows it to become a ceiling mounted camera as well. With video conferencing camera mounted on ceiling, the manual settings can be done so that the flipped image is broadcasted.

Image mirroring technology in VC520 Pro Pakistan.

The vc520pro video conferencing system allows manual selection of image mirroring as well. This allows the video conferencing system to enhance its capabilities even further.

Audio video conferencing system in Lahore (Project reference)

A complete audio video conferencing setup was established in Lahore for zoom based video conferencing solution.

vc520pro video conferencing system in Lahore
zoom based vc520pro video conferencing system in lahore

Video conferencing system in Islamabad

Complete audio video conferencing system comprising of Restmoment audio conference system & VC 520pro video conferencing system was installed.

vc520pro video conference system in islamabad
Installation of Vc520pro video conference camera system on LED TV

Best price of AVer VC-520pro Usb video conference system in Pakistan

For best price of AVer VC-520pro please get in touch with us at sales@nasco-av.com.

Specifications

  • Camera
    • Sony super-low-light 2M pixel sensor for clear and natural imaging in low-light conditions
    • Resolution: (16:9) 1920 x 1080, 1600 x 900, 1280 x 720, 960 x 540, 848 x 480, 800 x 448, 640 x 360, 424 x 240, 320 x 180; (4:3) 800 x 600, 640 x 480, 480 x 360, 320 x 240 at 60, 30, 15fps
    • SmartFrame for automatic FOV adjustment to fit all participants
    • True WDR up to 120dB: Superb backlight compensation technology for optimizing light balance in high-contrast conditions
    • Zoom: 18X total zoom (12X optical zoom)
    • Wide field of view (DFOV): 82°
    • Lens focal length: 3.9 mm (wide) ~ 47.3 mm (tele)
    • Lens F#: 1.8 (wide) ~ 2.8 (tele)
    • Mirror, Flip, AE, white balance: aut o, manual override via PTZApp
    • Minimum focus distance: 1.5 m
    • Standard tripod screw holes and Kensington slot
  • Motorized Pan & Tilt Movement
    • Pan: ±170°
    • Tilt: +90° (up) -30° (down)
    • 10 camera presets (through remote control)
    • Fast and quiet pan & tilt movement
  • Video Format
    • YUV, MJPEG, H.264
    • Network video compression format: H.264
    • Network protocols: RTSP, RTMP
  • Speakerphone
    • Full duplex microphone array with echo cancellation
    • Advanced noise suppression
    • Dual-microphone array
    • 3.5 mm phone-in jack
    • 3.5 mm line out
    • Speaker volume: Adjustable to 90dB SPL at 0.5 m
    • Microphone frequency response: 120Hz–16kHz
    • Microphone sensitivity: -34± 2 dBV @1KHz, 94dBSPL
    • Microphone distortion: < 1% from 150Hz
    • Microphone support range: Diameter 6M
    • Touch controls for volume down/up, mute, phone input, call, and hang-up
    • Bridge phone-in and USB into one call
    • Security: Kensington slot
  • Audio Format
    • AAC-LC
    • Network protocol: RTSP, RTMP
  • LAN
    • 10/100/1000 Mbps
  • Connectivity
    • 12V/5A power adaptor
    • Mini DIN9 for RS232 in & out connection (VISCA control panel and camera daisy-chain)
    • USB 3.1 Type-B connector
    • IP (RJ45)
  • USB
    • 3.1 Gen 1 Type-B, backward compatible with USB 2.0
    • UVC (USB video class) 1.1
    • UAC (USB audio class) 1.0
  • Control
    • IR remote control
    • VISCA/Pelco-P/Pelco-D via RS232 (128 preset points via VISCA command)
    • Remote side: VISCA over IP, IP (RJ45)
    • UVC/UAC plug-and-play
    • WebUI: Browser IP access via Chrome (does not support Internet Explorer)
    • PTZApp
  • Mount
    • Camera wall-mount bracket included
    • Optional foldable TV mount
  • System Requirements
    • Windows® 7/10
    • Mac OS X 10.13 or higher
    • Google Chromebook version 76.0.3809.102 or later
    • Android 6 or higher
  • Hardware Specs
    • 3.2 GHz Intel® Core™ i5-4460 Processor or higher
    • 4 GB RAM or more
    • USB 3.1 port, backward compatible with USB 2.0 port
  • Web page browser requirement
    • Chrome: version 76.x or above
    • Firefox: version 69 or above
    • IE: Not support
  • Power Supply
    • AC 100V ~ 240V, 50/60 Hz
    • Consumption: 12V, 5A
  • Free Applications for Meeting Collaboration (Windows® and Mac)
    EZManager: Camera Central Management software

    • Remotely group FW/SW upgrades, control the camera, and configure settings

    PTZApp

    • Upgrade firmware automatically or manually
    • Control camera
    • Set parameters and adjust camera image
    • Diagnose operating status
    • View live video

    EZLive

    • Real-time streaming / annotating / snapshots / video recording
  • Environmental Data
    • Operation temperature: 0°C ~ 40°C
    • Operation humidity: 20% ~ 80%
    • Storage temperature: -20°C ~ 60°C
    • Storage humidity: 20% ~ 80%
  • Dimensions
    • Package dimensions: 259 x 259 x 349 mm
    • Package weight: 5.4 kg
    • Camera: 142.7 x 153 x 182 mm/1.45 kg
    • Speakerphone: 220 x 181.5 x 49.5 mm/0.85 kg
    • Remote control: 200 x 50 x 21 mm/0.09 kg
  • Package Contents
    • VC520 Pro Camera
    • VC520 Pro Speakerphone
    • Remote control
    • Power adapter
    • Power cord (6 ft/1.8 m)
    • USB 3.1 Type-B to Type-A cable (10 ft/3 m)
    • CATE6 speakerphone cable (33 ft/10 m)
    • 3.5 mm aux cable (3 ft/0.9 m)
    • Quick-start guide
    • Warranty card
    • Wall-mount bracket
    • ¼” tripod screw
  • Optional Accessories
    • Mini DIN9 to RS232 adapter
    • Expansion Speakerphone (10 m cable included, daisy-chain up to three speakerphones)
    • Expansion Pair Microphone (Two 5 m cables included, daisy-chain up to four microphones)
    • Foldable TV mount
  • Warranty*
    • Camera / Speakerphone: 3+2 years (not available in US, JP, and certainother areas)
    • Accessories: 1 year

    * Please register online to receive a free 2-year warranty extension.
    For detailed warranty information, please contact an AVer representative.

  • Compatible Applications
    • Zoom, Microsoft® Teams, Skype for Business, Skype, Google Hangouts meet, Intel® Unite™, RingCentral, BlueJeans, V-Cube, LiveOn, CyberLink U Meeting®, TrueConf, Adobe® Connect™, Cisco Webex®, Fuze, GoToMeeting™, Microsoft® Lync™, Vidyo, vMix, WebRTC, Wirecast, XSplit

* Specifications may vary depending on countries and are subject to change without notice.
